WATCHPAX 40

4 x 4K WATCHOUT media server

Heading Generic 5

Compact and smart, the WATCHPAX 40 offers four times 4K playback, optimized playback performance for WATCHOUT shows, as well as EDID emulation and quick restore.

POWERFUL AND PORTABLE

Watchpax4 600X600

Practical, portable and perfectly at home in both permanent and temporary installs, new WATCHPAX 40 offers four 4K channels, 1 TB storage and a tech spec designed to do justice to your WATCHOUT shows! Built into the sleek, letter-size media server, you'll also find EDID emulation and smart restore/reset functions making it easier than ever to deploy on-site – and move on!

Download the product cutsheet here.

Read the press release!

Performance

Watchpax4 Back Cables To Right 500X500

• Plug and play – fast and easy to install
• Built-in WATCHOUT license
• Hardware EDID emulation/management
• Outputs –4x4K playback, DisplayPort
• Industrial-grade components, optimized for WATCHOUT
• Media storage –1TB (1GB/second) for fast playback of large files
• Network –1Gb Ethernet for high-speed transfer of content
• Optional 4K video capture and multi-channel audio – 2 × USB3 for flexibility
• Audio output –3.5 mm stereo

Installation

Watchpax4 Two Unit Rack 500X500

• Join two units for 19" rack installation
• Standalone or stack
• Quad fans for cooling
• Kensington security slot
• Clean shutdown and power up – IEC C14 input
• Two levels of reset
• Powers up and launches WATCHOUT automatically after power cut
• Locked-down unit

* Rack kit sold separately

Footprint

Watchpax4 Person Walking 500X500

• Width 214 mm, height 43 mm (1U), depth 276 mm (8.5 × 1.7 × 11 inches)
• Light, just 2950 g (6.7 lbs)
• Sleek look – locate it close to displays and avoid long cable runs
• Robust aluminium housing
• Strap for hand carrying
• Removable rubber bumpers

FEATURES & SPECIFICATIONS



FEATURE

WATCHPAX 40

WATCHOUT

Included

Max output resolution per channel

Up to 4096 x 2160

Video playback

Up to 4K per channel

Output channels

4 x DisplayPort

Capture

Newtek NDI and USB (3rd party component required)

Storage

1 TB

Audio output

1 x 3.5 mm stereo audio out

USB

2 x USB3

Ethernet, 1 Gb

Yes

INSTALLATION

Size

214 x 276 x 43 mm (1 U)

Weight

2.95 kg (6.5 lbs)

Housing

Aluminum, black finish

Kensington security slot

Yes

EDID emulation

Yes

Quick restore/reset

Yes

Rack

Connect two units for 19-inch rack install
